HTP-S2
Item
Parameters
Unit
Container
Max Container volume
L
7
Max Inlet outer Diameter
mm
120
Max Container Diameter
200
Max Container Height
335
Number Of Cavities
PC
1
Theoretical Output
Bph
800(*)
Electrical
Installed Power
KW
63
Max Heating Power
60
Compressed air
Operating Pressure
Mpa
0.7
Low Pressure Air Consuming
L/min
1800
Blowing Pressure
2.5
High Pressure Air Consuming
1500¡ª3000(**)
Chiller Water
Pressure
0.3¡ª0.5
Temperature
¡æ
10¡ª12
Flow Rate
30
Machine Dimension
Size(L¡ÁW¡ÁH)
M
3¡Á2.2¡Á2.2
Weight
KG
3000
