| Parameters£º |
HTP-R8 Specifications
|
Item |
Parameters |
Unit |
HTP-R8 |
|
Container |
Max Container volume |
L |
2 |
|
Max Inlet outer Diameter |
mm |
38 |
|
Max Container Diameter |
mm |
120 |
|
Max Container Height |
mm |
320 |
|
Number of Cavities |
PET |
8 |
|
Theoretical Output |
500ml,Bph |
8500 |
|
Electrical |
Installed Power |
KW |
4 |
|
Max Heating Power |
KW |
200 |
|
Compressed air |
Operating Pressure |
Mpa |
0.8 |
|
Low Pressure Air Consuming |
L/min |
7000 |
|
Blowing Pressure |
Mpa |
3.8 |
|
High Pressure Air Consuming |
L/min |
8000 |
|
Chiller Water |
Pressure |
Mpa |
0.3¡ª0.5 |
|
Temperature |
¡æ |
10¡ª12 |
|
Flow Rate |
L/min |
25 |
|
Machine Dimension |
Size(L¡ÁW¡ÁH) |
M |
2.1¡Á2.9¡Á3.1 |
|
Weight |
KG |
8500 | |
|
