HTP-2Ⅱ specifications
Item
Parameters
Unit
HTP-2Ⅱ
Container
Max Container volume
L
0.03-2.0
Max Inlet outer Diameter
mm
28-80
Max Container Diameter
95
Max Container Height
330
Number of Cavities
PET
1-2
Theoretical Output
Bph
300-600
Electrical
Installed Power
KW
4
Max Heating Power
8
Compressed air
Operating Pressure
Mpa
0.7
Low Pressure Air Consuming
L/min
800
Blowing Pressure
1-3
High Pressure Air Consuming
900
Chiller Water
Pressure
0.3-0.5
Temperature
℃
10-12
Flow Rate
25
Machine Dimension
Size(L×W×H)
M
1.3x0.5x2.0
Weight
KG
850
