HTP-5¢ò Specifications
Item
Parameters
Unit
HTP-5¢ò
Container
Max Container volume
L
5 / 0.03-2
Max Inlet outer Diameter
mm
28-90
Max Container Diameter
200
Max Container Height
330
Number Of Cavities
PC
1 / 2
Theoretical Output
Bph
250 / 500
Electrical
Installed Power
KW
4
Max Heating Power
8
Compressed air
Operating Pressure
Mpa
0.7
Low Pressure Air Consuming
L/min
1800
Blowing Pressure
2.5
High Pressure Air Consuming
1500¡ª3000(**)
Chiller Water
Pressure
0.3-0.5
Temperature
¡æ
10-12
Flow Rate
30
Machine Dimension
Size(L¡ÁW¡ÁH)
M
1.7¡Á0.6¡Á2.2
Weight
KG
930
