SYSTEM

ITEM

UNIT

HTB-80

Parameters

Material

PE PP ABS

Max container capacity

L

30

Output(dry cycle)

Pc/hr

360

Machine dimension(LxWxH)

M

4.7X2.6X4

Total weight

T

12

Clamping system

Clamping force

KN

200

Platen opening stroke

mm

400-900

Platen size

mm

880X800

Max mould size(WxH)

mm

660X1000

Mould thickness

mm

450-510

Overall dimension(LxWxH)

M

4.7X1.5X1.8

Extrusion system

Screw Dia

mm

80

Screw L/D ratio

L/D

24

Plasticzing capacity(HDPE)

Kg/hr

120

Number of heating zone

zone

4

Extruder heating power

KW

21.4

EXtruder driving power

KW

30

Overall dimension(LxWxH)

M

3.8X1.96X1.4

Die head

Number of heating zone

zone

4

Power of die heating

KW

21.3

Max die-pin diameter

mm

250

Accumlator capacity

L

5

Overall dimension ess(LxWxH)

M

2.15X0.9X0.55

Power

Max drive

KW

67

Total power

KW

82

Fan power for screw

KW

0.5

Air pressure

Mpa

1

Air consumption

M3/min

0.8

Average energy consumption

KW

38
